The linear axis with ballscrew and steel profile is a compact, flexible positioning module. It is ideal in particular for applications requiring high rolling moments around the axis.
Konfigurátor
Nájdených 46 výrobkov
  • 1(current)
  • 2
  • 3
Typ
Profile width
Lead
Max. stroke
vmax
amax
Repeatability
KK3001P0075
 30 1 25 0,16 5 ± 0,003
KK3001P0100
 30 1 50 0,16 5 ± 0,003
KK3001P0125
 30 1 75 0,16 5 ± 0,003
KK3001P0150
 30 1 100 0,16 5 ± 0,003
KK3001P0175
 30 1 125 0,16 5 ± 0,003
KK3001P0200
 30 1 150 0,16 5 ± 0,003
KK4001P0100
 40 1 30 0,19 5 ± 0,003
KK4001P0150
 40 1 80 0,19 5 ± 0,003
KK4001P0200
 40 1 130 0,19 5 ± 0,003
KK5002P0150
 50 2 60 0,27 5 ± 0,003
KK5002P0200
 50 2 110 0,27 5 ± 0,003
KK5002P0250
 50 2 160 0,27 5 ± 0,003
KK5002P0300
 50 2 210 0,27 5 ± 0,003
KK6005P0150
 60 5 50 0,55 15 ± 0,003
KK6005P0200
 60 5 100 0,55 15 ± 0,003
KK6005P0300
 60 5 200 0,55 15 ± 0,003
KK6005P0400
 60 5 300 0,55 15 ± 0,003
KK6005P0500
 60 5 400 0,55 15 ± 0,003
KK6005P0600
 60 5 500 0,34 15 ± 0,003
KK6010P0150
 60 10 50 1,1 15 ± 0,003
